In a high-end villa area in Qatar, Sunray has successfully created a breakthrough intelligent sunroom project. The project is located in the tropical desert climate zone at 25°16’N latitude, facing severe environmental challenges such as extreme heat, strong UV rays and frequent sand and dust.
customer expectation：
The client wanted to create a modern sunroom that could withstand temperatures up to 50°C, block strong ultraviolet rays, and have intelligent dimming functions, while maintaining architectural aesthetic unity and low maintenance costs.
The “Four Dimensions of Integration” innovative design program：
1) The material is made of triple composite glass (6mm+1.52PVB+6mm Low-E) and aviation grade 6063-T5 aluminum alloy frame;
(2) Intelligent system equipped with electrochromic dimming
3) The protection system adopts high-density dustproof screen mesh and intelligent motorized sunshade
4) Aesthetic treatment with hidden nodes and customized surface treatment
Project results：
It maintains a comfortable temperature difference of 8-10℃ during midday hours, reduces energy consumption by 35%, has a UV blocking rate of >99%, and extends the cleaning cycle to 180 days/times. This successful case not only meets all the needs of the owner, but also sets a new benchmark for building solutions under extreme climate conditions in the Middle East.
